3.6 Volt ER26500 Titus C Primary Lithium Battery (8500 mAh)

SKU: 76063

Titus

$15.99
(No reviews yet) Write a Review
Adding to cart… The item has been added

Compatible Products

Description
Specifications
  • Size: C
  • Capacity: 8500mAh
  • Chemistry: Lithium Thionyl Chloride (Li-SOCI2)
  • Voltage: 3.6V
  • Brand: Titus
  • Hermetic glass-to-metal sealing.
  • Non-flammable electrolyte.
  • UL Approved --- BBCV2.MH30127

Electrical characteristics

  • Nominal capacity 8.5Ah ( 8500 mAh)
  • Open circuit voltage(at +20C +68F) 3.66V
  • Nominal voltage(at 1mA +20C +68F) 3.6V
  • Pulse capability: Typically up to 400 mA
  • Max. Continuous current: 200mA Max
  • Pulse current: 400mA
  • Storage (recommended) +30C +86 F max
  • Operating temperature range -55C / +85C
  • lithium-thionyl chloride(Li-SOCl2) technology
  • Self discharge is low at less than 1% per annum at +68F, giving an effective shelf life of 10 years.
  • Diameter(max): 26.2mm (1.02 in)
  • Height (max): 50.5mm (1.98 in)
  • Typical weight: 55g (1.8 oz)

Equivalent Batteries

  • LS26500, LS26500C, TL-4920, TL-5920, TL-2200,
  • SB-C01, SB-C02, SL-770, XL-140F, XL-145F, PT-2200
  •
  • Main applications:
  • Radio communication and other military applications
  • Alarms and security systems
  • Beacons and emergency location transmitters
  • GPS
  • Metering systems
  • Sonobuoys
  • LED lighting applications
  • Memory backup for computers
  • Others
  •
  • Lithium Thionyl Chloride has the highest energy density of any practical Lithium battery chemistry, three times greater than Alkaline (Zinc Manganese Dioxide) batteries.

⚠️ Warning

  • This is not rechargeable battery. Do not try to recharge it
  • The storage area should be clean, cool (not exceeding +30 Deg C ), dry and ventilated
  • Do not use if the battery casing was mangled.
  • Please discharge the battery few minutes with 100mA,if the battery voltage is lower than your need or consult ABLE.
  • Don't use different models of battery in series.
  • Soldering the tag should be finished in few seconds.
  • This is not high drain battery, please don't use it for application with discrging current > 200mA

3.6 VOLT ER26500 TITUS C PRIMARY LITHIUM BATTERY (8500 MAH)


Powerful Performance: The ER26500 Titus C Primary Lithium Battery



In an age where reliable power is paramount, the ER26500 Titus C Primary Lithium Battery emerges as a powerhouse solution, boasting impressive capacity and versatility.



Unparalleled Features for Exceptional Performance

The ER26500 Titus C Primary Lithium Battery is engineered to deliver outstanding performance across a wide range of applications. Let's explore its standout features:

High Capacity: With a nominal capacity of 8.5Ah (8500mAh), the ER26500 battery provides ample power to sustain devices for extended periods, ensuring continuous operation without the need for frequent replacements.
Wide Operating Temperature Range: From extreme cold to scorching heat, the ER26500 battery maintains reliable performance in diverse environmental conditions. With an operating temperature range spanning from -55°C to +85°C, it excels in harsh and demanding applications.
Low Self-Discharge: The ER26500 battery boasts a low self-discharge rate of less than 1% per annum at +68°F, offering an effective shelf life of up to 10 years. This ensures that stored batteries retain their charge effectively, ready to power devices whenever needed.
Hermetic Glass-to-Metal Sealing: Designed with hermetic glass-to-metal sealing, the ER26500 battery provides enhanced durability and reliability, ensuring that it performs consistently in challenging environments without compromising safety or functionality.
Non-Flammable Electrolyte: Safety is paramount in battery technology, and the ER26500 battery prioritizes safety with its non-flammable electrolyte, minimizing the risk of accidents or hazards during operation.
UL Approval: The ER26500 battery is UL-approved, meeting stringent quality and safety standards, further underscoring its reliability and suitability for a wide range of applications.


Versatile Applications for Diverse Needs

The ER26500 Titus C Primary Lithium Battery finds application across various industries and sectors, thanks to its versatility and robust performance. Here are some examples of where this battery excels:

Radio Communication and Military Applications: The ER26500 battery powers critical communication equipment and military devices, ensuring reliable operation in mission-critical scenarios.
Alarms and Security Systems: From home security systems to industrial alarms, the ER26500 battery provides the power needed to keep properties and assets safe and secure.
Beacons and Emergency Location Transmitters: In emergency situations, beacons and location transmitters rely on the ER26500 battery for dependable power, facilitating swift and effective response efforts.
GPS Devices: Navigational devices and GPS trackers benefit from the long-lasting power provided by the ER26500 battery, ensuring accurate positioning and tracking capabilities.
Metering Systems: Utility meters, industrial instrumentation, and metering systems leverage the ER26500 battery's reliability and longevity for accurate data collection and monitoring.
LED Lighting Applications: Whether in outdoor fixtures or portable lighting solutions, LED lighting applications utilize the energy density of the ER26500 battery for bright and efficient illumination.
Memory Backup for Computers: Safeguarding critical data and system settings, the ER26500 battery serves as a reliable backup power source for computers and memory systems.


Experience Unmatched Power with the ER26500 Titus C Primary Lithium Battery

The ER26500 Titus C Primary Lithium Battery stands as a testament to power and reliability in the realm of battery technology. With its high capacity, wide operating temperature range, and versatility, it's the ideal choice for powering critical systems and devices across industries. Experience the unmatched power of the ER26500 battery and unlock new possibilities for your applications.
