T4 4 Slot Smart Charger + 2 x AA 3.2 Volt 600 mAh LiFePO4 14500 Batteries

SKU: 73260

Rydelec

Was: $49.39
Now: $45.99
(No reviews yet) Write a Review
Adding to cart… The item has been added

Compatible Products

Description

Charger Specifications

  • Input Voltage: AC 100-240V 50/60Hz or DC 12V
  • Output Voltage: DC 4.2V, 3.6V, 1.48V
  • Output Current: 425mA x 4/ 850mA x2
  • Dimensions: 137 mm x 97 mm x 40.5 mm
  • Weight: 206g (without batteries and power cord)

    Compatible with:
  • 3.7V Li-ion / 3.2V LiFePO4: 10400, 14430, 14500, 16340 (RCR123), 17335, 17500, 17670, 18500, 18650, 22650, 26650.
  • Ni-MH / Ni-CD: AA, AAA, C, Sub C

Charger Features

  • Capable of charging 4 batteries simultaneously
  • Each of the four battery slots monitors and charges independently
  • Automatically identifies Li-ion, Ni-MH and Ni-Cd rechargeable batteries*
    * Note: for LiFePO4 batteries select LiFePO4 battery type switch.
  • Features three charging modes (CC, CV and Trickle Charge)
  • Automatically detects battery status and selects the appropriate voltage and charge mode
  • 3 LED lights display charging progress for each battery individually
  • Automatically stops charging when complete
  • Features reverse polarity protection
  • Designed for optimal heat dissipation
  • Certified by CE

Battery Specifications

  • Nominal Voltage: 3.2 Volt
  • Size: AA 14505 or 14500
  • Capacity: 600 mAh (Replaces 500 mAh / 400 mAh / 250 mAh and more)
  • Chemistry: Lithium Phosphate (LiFePO4)
  • Max Charging Current: 0.6A
  • Max Discharging Current: 0.6A
  • Energy Density: 96.96 wh/kg
  • Brand: Power Portable
  • Included Qty: 2
  • Length: 50 mm (1.97")
  • Diameter: 14 mm (0.55")
  • Weight: 19.8 g (0.78 Oz)

Battery Features

  • No memory effect
  • Long storage life
  • Light weight and high energy density
  • same size as an AA size battery, but has 3 times higher voltage
  • Up to 1000 Charge Cycles

T4 4 SLOT SMART CHARGER + 2 X AA 3.2 VOLT 600 MAH LIFEPO4 14500 BATTERIES


T4 4 Slot Smart Charger:



Input Voltage: Supports both AC 100-240V 50/60Hz and DC 12V input, providing flexibility for various power sources.
Output Voltage: Offers multiple output voltages including DC 4.2V, 3.6V, and 1.48V, ensuring compatibility with a wide range of batteries.
Output Current: Capable of delivering a maximum output current of 425mA x 4 or 850mA x 2, allowing for efficient and simultaneous charging of up to four batteries.
Dimensions: Compact dimensions of 137 mm x 97 mm x 40.5 mm make it space-efficient and suitable for various environments.
Weight: Weighing 206g (without batteries and power cord), it is lightweight and portable.
Compatibility: Compatible with various battery types including 3.7V Li-ion, 3.2V LiFePO4, Ni-MH, and Ni-CD, ensuring versatility in charging options.
Charging Modes: Features three charging modes (CC, CV, and Trickle Charge) for optimized charging performance and battery health.
Battery Monitoring: Monitors and charges each battery slot independently, with LED lights displaying charging progress for each battery individually.
Safety Features: Includes reverse polarity protection, ensuring safety during battery insertion, and optimal heat dissipation design for efficient cooling.
Certification: Certified by CE, indicating compliance with international safety and quality standards.


2 x AA 3.2 Volt 600 mAh LiFePO4 14500 Batteries:

Nominal Voltage: Operates at a nominal voltage of 3.2V, suitable for devices compatible with this voltage range.
Size: Sized similarly to standard AA batteries, with dimensions of 50 mm (length) x 14 mm (diameter), ensuring compatibility with devices designed for AA batteries.
Capacity: Each battery offers a capacity of 600 mAh, providing reliable and long-lasting power for various applications.
Chemistry: Utilizes Lithium Phosphate (LiFePO4) chemistry, known for its stability, safety, and high energy density.
Max Charging/Discharging Current: Supports a maximum charging and discharging current of 0.6A, ensuring efficient charging and power delivery.
Energy Density: Boasts a high energy density of 96.96 wh/kg, providing ample power in a compact size.
Memory Effect: Free from memory effect, allowing for flexible recharging without capacity loss.
Longevity: Offers up to 1000 charge cycles, ensuring durability and longevity for prolonged use.


The T4 4 Slot Smart Charger and the 2 x AA 3.2 Volt 600 mAh LiFePO4 14500 Batteries provide a reliable and efficient charging solution for LiFePO4 batteries, with versatile compatibility and safety features ensuring optimal performance and longevity.
