Description

The Saft LS145003PFRP AA 3.6 Volt 2600 mAh Lithium Battery with PC Mount is a high-performance lithium-thionyl chloride battery engineered for industrial electronics, PLC systems, memory backup, metering, alarms, security equipment, and embedded electronic devices. Featuring a PCB mount design with one positive pin and two negative pins, it provides secure installation and dependable long-term power.

Built using Saft's proven lithium-thionyl chloride technology, this non-rechargeable AA battery delivers stable 3.6V output, exceptional reliability, low self-discharge, and outstanding performance across a wide temperature range. Its high energy density and long shelf life make it ideal for critical applications where dependable backup power is essential.

Specifications

Brand:	Saft
Model:	LS145003PFRP
Chemistry:	Lithium Thionyl Chloride (Li-SOCl2)
Nominal Capacity:	2600 mAh
Open Circuit Voltage:	3.67 Volt
Nominal Voltage:	3.6 Volt
Nominal Energy:	9.36 Wh
Pulse Capability:	Typically up to 250 mA
Max. recommended continuous current:	50 mA
Storage:	+30°C (+86°F) max
Operating Temperature Range:	-60°C to +85°C (-76°F to +185°F)
Battery Size:	AA
Dimensions:	14.5mm Diameter × 50.3mm Height
Terminal:	PC Mount - 1 Pin Positive, 2 Pins Negative

Features

Key Features:

• High energy density lithium-thionyl chloride chemistry
• Stable 3.6V output throughout battery life
• 2600mAh capacity for long-lasting performance
• PCB mount design with 1 positive pin and 2 negative pins
• Very low self-discharge for extended shelf life
• Wide operating temperature range from -60°C to +85°C
• Ideal for PLC systems, memory backup, meters, alarms, and industrial electronics
• Excellent resistance to humid environments
• Non-flammable inorganic electrolyte
• Non-rechargeable primary lithium battery

COMPATIBILITY

Also Known As:

• LS145003PFRP
• LS14500 3PFRP
• ER14505 PC Mount
• AA 3.6V Lithium Battery
• PLC Backup Battery
• Memory Backup Battery
• 3-Pin PCB Mount Lithium Battery

Common Applications:

• PLC Systems
• Memory Backup
• Real-Time Clocks
• Industrial Controls
• Utility Metering
• Alarm & Security Systems
• Electronic Toll Collection
• Embedded Electronic Equipment
