- Voltage: 3.6 Volt
- Capacity: 1.2 Ah
- Size: 1/2 AA
- Chemistry: Lithium Thionyl Chloride (Li-SOCI2)
- Brand: Tadiran
- Termination Style: Button Top
- Shelf Life: 10+ Years
- Maximum Recommended Continuous Current: 20 mA
- Maximum Pulse Current Capability: 50 mA
- Diameter (max): 14.5 mm (0.57 in)
- Height (max): 25.2 mm (0.99 in)
- Typical Weight: 9.6g (0.39 oz)
- High operating voltage, stable during most of the application lifetime
- Some of the highest nominal capacities on the market today
- Excellent reliability over extended operating life
- Operating Temperature Range: -60°C/+85°C (-76°F/+185°F)
- Low self-discharge rate (less than 1% after 1 year of storage at + 20°C)
- Excellent resistance to humid environments
- Low magnetic signature
- Non-flammable (and non-pressurized at ambient temperature) inorganic (but corrosive) electrolyte
- Less than 1% capacity loss during storage at ambient temperature before use
- Tadiran TL-5902
- Tadiran TL-2150
- Tadiran TL-5101
- Tadiran TLL-5902
- Tadiran TL-5111
- Saft LS-14250
- Saft LS-14250c
- Toshiba ER3v
- Sonnenschein SL-350/S
- Sonnenschein SL-750/S
- Sonnenschein SL-150/S
- This battery is not rechargeable. Do not try to recharge.
- The storage area should be clean, cool (not exceeding +30 Deg C ), dry and ventilated.
- Don't use different models of battery in series.
- Soldering the tab should be finished in few seconds.
- Do not use if the battery casing was mangled.
