Description
The RCR123A 3.6V 1000mAh Rechargeable Battery with PCB provides rechargeable power for compatible electronic equipment designed to operate with a protected RCR123A lithium-ion battery. Featuring lithium-ion (Li-ion) rechargeable chemistry, this battery delivers a nominal voltage of 3.6 volts and a capacity of 1000 mAh (1 Ah). Its compact RCR123A cylindrical format is suitable for compatible LED flashlights, portable lighting equipment, electronic instruments, specialized photographic accessories, and other electronic devices specifically designed for rechargeable 3.6V lithium-ion cells. The integrated protection circuit board (PCB) provides an additional layer of electrical protection during normal operation.
Designed in the RCR123A rechargeable battery format, this lithium-ion cell measures 34.0 × 16.0 mm (1.34 × 0.63 in), length × diameter (16340 size; PCB-protected cells can be slightly longer), and features a raised button-top positive terminal and a flat negative terminal for compatible battery compartments. Its built-in PCB protection circuitry is designed to help protect against overcharging, excessive discharge, overcurrent, and short-circuit conditions within the limits of the protection circuit. The battery is rechargeable using a compatible lithium-ion charger designed for this type of cell. The protection circuit may increase the battery's overall length compared with an unprotected RCR123A or standard primary CR123A battery, making it important to confirm the available battery compartment clearance before installation.
The RCR123A 3.6V 1000mAh Rechargeable Battery with PCB is intended for equipment specifically approved for rechargeable lithium-ion batteries with a nominal voltage of 3.6V. Although it has a similar cylindrical format to a standard CR123A primary lithium battery, it is not automatically interchangeable with a non-rechargeable 3.0V CR123A because of differences in operating voltage, fully charged voltage, chemistry, and charging requirements. Standard rechargeable lithium-ion cells in this voltage class can reach 4.2V when fully charged, and equipment must be designed to tolerate the applicable voltage range. Always verify the equipment manufacturer's specified battery chemistry, nominal voltage, maximum operating voltage, terminal configuration, physical dimensions, discharge requirements, and approved replacement specifications before installation. Each purchase includes one RCR123A 3.6V 1000mAh Rechargeable Battery with PCB.
|
|
Specifications
| Product Name: |
RCR123A 3.6V 1000mAh Rechargeable Battery with PCB |
| Battery Model: |
RCR123A |
| Battery Size: |
RCR123A / 16340 Format |
| Battery Type: |
Protected Rechargeable Cylindrical Lithium-Ion Battery |
| Chemistry: |
Lithium-ion (Li-ion), secondary, rechargeable |
| Voltage: |
3.6–3.7 V nominal, 4.2 V full charge |
| Capacity: |
1000 mAh (1 Ah) |
| Fully Charged Voltage: |
4.2 V |
| Battery Format: |
RCR123A Rechargeable Cylindrical Cell |
| Dimensions: |
34.0 × 16.0 mm (1.34 × 0.63 in), length × diameter (16340 size; PCB-protected cells can be slightly longer) |
| Protection Circuit: |
Integrated PCB Protection |
| Protection Functions: |
Overcharge, Overdischarge, Overcurrent, and Short-Circuit Protection |
| Terminal: |
Button top |
| Positive Terminal: |
Raised button top |
| Negative Terminal: |
Flat |
| Rechargeable: |
Yes |
| Charging Method: |
Compatible Lithium-Ion CC/CV Charger |
| Charger Compatibility: |
Charger Approved for 3.6V Nominal Lithium-Ion RCR123A Cells |
| Primary Applications: |
Compatible LED Flashlights, Portable Lighting, Electronic Instruments, Photographic Accessories, Specialized Portable Electronics |
| Battery Quantity: |
1 Battery |
| Packaging: |
Single RCR123A 3.6V 1000mAh Rechargeable Battery with PCB |
| Battery Charger Included: |
No |
|
|
COMPATIBILITY
Common Applications:
- Compatible RCR123A Rechargeable Lithium-Ion Battery Devices
- Compatible 3.6V RCR123A Battery Compartments
- Compatible Protected 16340 Lithium-Ion Battery Devices
- Compatible Rechargeable LED Flashlights
- Compatible Compact LED Flashlights
- Compatible Handheld LED Lighting Equipment
- Compatible Professional Portable Lighting Equipment
- Compatible Rechargeable Flashlight Accessories
- Compatible Portable Electronic Instruments
- Compatible Handheld Electronic Measuring Equipment
- Compatible Electronic Testing Instruments
- Compatible Photographic Accessories
- Compatible Camera Accessories Approved for 3.6V RCR123A Batteries
- Compatible Specialized Electronic Equipment
- Compatible Electronic Monitoring Equipment
- Compatible Portable Industrial Instruments
- Compatible Rechargeable Electronic Devices
- Compatible Professional Electronic Accessories
- Compatible Battery-Powered Inspection Equipment
- Compatible Portable Electronic Tools
- Other Devices Specifically Approved for Protected 3.6V RCR123A Lithium-Ion Batteries
Also Known As / Replaces:
- RCR123A
- RCR-123A
- RCR 123A
- RCR123A 3.6V Rechargeable Battery
- RCR123A 1000mAh Rechargeable Battery
- RCR123A 3.6V 1000mAh Battery
- RCR123A Lithium-Ion Battery
- RCR123A Li-Ion Rechargeable Battery
- RCR123A Protected Lithium-Ion Battery
- RCR123A Battery with PCB
- RCR123A PCB Protected Battery
- RCR123A Button-Top Rechargeable Battery
- 16340 Rechargeable Lithium-Ion Battery
- 16340 Protected Lithium-Ion Battery
- 16340 3.6V Rechargeable Battery
- 16340 1000mAh Rechargeable Battery
- 16340 Button-Top Lithium-Ion Battery
- 16340 PCB Protected Battery
- 3.6V Rechargeable CR123A-Format Battery
- 3.6 Volt Protected RCR123A Battery
- 1000mAh Protected RCR123A Battery
- Rechargeable RCR123A Flashlight Battery
- Protected Lithium-Ion Flashlight Battery
- Other Protected RCR123A / 16340 Lithium-Ion Batteries with Matching Voltage, Capacity Requirements, Dimensions, Terminal Configuration, and Discharge Specifications
Important Compatibility Note:
- BATTERY MODEL: RCR123A.
- BATTERY SIZE: RCR123A / 16340 cylindrical battery format.
- BATTERY TYPE: Protected rechargeable cylindrical lithium-ion battery.
- BATTERY CHEMISTRY: Lithium-ion (Li-ion), secondary, rechargeable.
- VOLTAGE: 3.6 V nominal.
- CAPACITY: 1000 mAh (1 Ah).
- FULLY CHARGED VOLTAGE: 4.2 V for standard lithium-ion chemistry.
- DIMENSIONS: 34.0 × 16.0 mm (1.34 × 0.63 in), length × diameter.
- PROTECTION CIRCUIT: Integrated PCB protection.
- PROTECTION FUNCTIONS: Overcharge, overdischarge, overcurrent, and short-circuit protection.
- TERMINAL: Button top.
- POSITIVE TERMINAL: Raised button top.
- NEGATIVE TERMINAL: Flat.
- BATTERY QUANTITY: 1 battery.
- RECHARGEABLE: Yes. This is a secondary lithium-ion battery designed for compatible rechargeable applications.
- CHARGING METHOD: Use a compatible lithium-ion CC/CV charger approved for this battery chemistry and voltage.
- CHARGER COMPATIBILITY: Confirm that the charger supports 3.6V nominal lithium-ion RCR123A batteries.
- DEVICE COMPATIBILITY: Use only in equipment approved for protected 3.6V RCR123A rechargeable lithium-ion batteries.
- VOLTAGE COMPATIBILITY: Confirm that the equipment supports the battery's nominal voltage and full operating voltage range.
- FULL-CHARGE WARNING: A standard lithium-ion battery with a nominal voltage of 3.6V can reach 4.2V when fully charged.
- Equipment designed exclusively for 3.0V primary lithium batteries may not tolerate the higher voltage of a fully charged RCR123A lithium-ion battery.
- CR123A WARNING: Standard CR123A batteries are primary, non-rechargeable lithium cells with a nominal voltage of 3.0V.
- Do not assume that a rechargeable RCR123A battery is a direct replacement for a non-rechargeable CR123A battery.
- CR123A REPLACEMENT: Use this battery in equipment originally designed for CR123A only when the equipment manufacturer specifically approves rechargeable 3.6V lithium-ion replacements.
- LiFePO4 WARNING: Rechargeable lithium iron phosphate RCR123A batteries have different nominal voltages and charging requirements.
- Do not substitute this lithium-ion battery for a 3.2V LiFePO4 battery unless the equipment manufacturer specifically approves the substitution.
- REGULATED 3.0V WARNING: Some rechargeable RCR123A batteries use internal voltage regulation to provide a 3.0V output. These are not electrically equivalent to a conventional 3.6V lithium-ion RCR123A cell.
- BATTERY CHEMISTRY COMPATIBILITY: Confirm that the equipment manufacturer approves rechargeable lithium-ion chemistry.
- PHYSICAL COMPATIBILITY: Confirm that the battery fits the intended compartment and that the terminals make proper electrical contact.
- PROTECTED BATTERY SIZE WARNING: The integrated PCB and terminal construction may increase the overall battery length compared with an unprotected RCR123A or primary CR123A cell.
- Confirm battery compartment clearance before installation, especially in devices with tightly fitted battery compartments.
- TERMINAL COMPATIBILITY: Verify that the button-top positive terminal and flat negative terminal match the equipment's battery contacts.
- DISCHARGE COMPATIBILITY: Confirm that the battery and protection circuit can safely supply the equipment's continuous and peak current requirements.
- PROTECTION CIRCUIT LIMITATIONS: PCB protection does not make the battery immune to misuse, mechanical damage, overheating, or incompatible charging conditions.
- OVERCHARGE PROTECTION: The PCB is designed to help interrupt charging under specified overvoltage conditions.
- OVERDISCHARGE PROTECTION: The PCB is designed to help limit excessive discharge under specified conditions.
- OVERCURRENT PROTECTION: The PCB is designed to help interrupt excessive current under specified conditions.
- SHORT-CIRCUIT PROTECTION: The PCB is designed to help interrupt short-circuit current under specified conditions.
- Do not intentionally short-circuit the battery to test its protection circuitry.
- CHARGING SAFETY: Use only an appropriate lithium-ion charger and follow the battery and charger manufacturers' instructions.
- Do not use a charger intended exclusively for NiCd, NiMH, or LiFePO4 batteries.
- Do not exceed the battery manufacturer's specified charging voltage or charging current.
- Do not charge a damaged, leaking, swollen, overheated, or otherwise abnormal battery.
- Do not leave charging batteries unattended or charge them near combustible materials.
- BATTERY REPLACEMENT: Match the equipment manufacturer's specified battery chemistry, nominal voltage, full operating voltage range, dimensions, terminal configuration, and discharge requirements.
- Do not substitute batteries with incompatible voltages, chemistries, charging requirements, or discharge characteristics unless specifically approved by the equipment manufacturer.
- Do not mix rechargeable lithium-ion batteries with primary lithium, LiFePO4, alkaline, NiMH, or other battery chemistries in the same equipment.
- When multiple batteries are required, use batteries of the same approved chemistry, compatible specifications, and similar condition.
- Do not mix new and used batteries or batteries with substantially different charge levels in the same device.
- Replace or recharge multiple-cell battery sets according to the equipment manufacturer's instructions.
- Actual battery operating time depends on equipment power consumption, discharge conditions, and operating temperature.
- Always observe the correct positive (+) and negative (-) polarity during installation and charging.
- Do not short-circuit the battery terminals or allow conductive objects to bridge the positive and negative contacts.
- Do not crush, puncture, disassemble, modify, overheat, or expose the battery to fire.
- Do not attempt to solder directly to the battery terminals or casing.
- Do not remove, bypass, or modify the integrated protection circuit.
- Do not immerse the battery in water or other liquids.
- Do not use batteries that are damaged, leaking, swollen, deformed, or showing signs of excessive heat.
- Stop using or charging the battery immediately if it becomes unusually hot, emits an unusual odor, or shows signs of damage.
- Keep batteries away from children and pets.
- Store unused batteries in a cool, dry location away from direct sunlight, excessive heat, and conductive metal objects.
- Protect battery terminals against accidental short circuits during storage and transportation.
- For extended storage, follow the battery manufacturer's recommended charge level and storage instructions.
- Dispose of or recycle used rechargeable lithium-ion batteries in accordance with applicable local regulations and available battery collection programs.
Package Includes:
- 1 × RCR123A 3.6V 1000mAh Rechargeable Battery with PCB
- Capacity: 1000 mAh (1 Ah)
- Integrated PCB Protection Circuit
- Terminal: Button top
- Total Quantity: 1 Battery
- Rechargeable Lithium-Ion Battery
- Battery Charger Not Included
|
