18.5 Volt Lithium Ion Battery Pack (2600 mAh) with Protection IC

Specifications:

• Li-Ion Size: 5 x 18650 (cylindrical)
• Capacity: 2600 mAh
• Chemistry: Lithium Ion (Li-Ion)
• Working Voltage: 18.5V
• Peak Voltage: 21V
• Cut off voltage: 12.5V
• Max Charging Current: 2 Amp
• Protection: PCB - 7 Amp (Protects from Overcharge, Overdischarge, Over Drain and Short Circuits)
• Protection: Polyswitch - 7 amp (Limits Max Discharge and Protect wrong Polarity)
• Max Discharging Current: 7 Amp Instant Current (Limited by Polyswitch); 5.2A Max Continous Current
• Length: 3.6" (92mm)
• Width: 2.8" (71mm)
• Height: 1" (25mm)
• Weight: 8.5 Oz (241 Gr)

Features

• No memory effect
• Longer storage life then NiMH Batteries
• Light weight and higher energy density than any rechargeable battery
• Installed PCB (7 Amp) will prevent the battery pack from over charge (> 21V), over discharge(< 12.5 V), Overdrain (> 7.0Amp) and Short Circuits. It helps protect battery chemistry integrity and prolongs battery life.
• 7 Amp polyswitch installed to limit max. discharging current at 7 A and to protect wrong polarity.
• The battery module is wrap by PVC shrink and with 18 G wire leads
• UN38.3 Passed for safe transport
