12-Pack SAFT LS17330 (ER17730) 3.6 Volt 2/3 A 2100 mAh Lithium Batteries

12-Pack SAFT LS17330 (ER17730) 3.6 Volt 2/3 A 2100 mAh Lithium Batteries

SKU: 75298

SAFT

$112.69
(No reviews yet) Write a Review
Adding to cart… The item has been added

Compatible Products

Description

Specifications

  • Voltage: 3.6 Volt
  • Capacity: 2100 mAh
  • Chemistry: Lithium Thionyl Chloride (Li-SOCI2)
  • Brand: Saft
  • Concentric (“bobbin”) electrodes
  • Hermetic glass-to-metal sealing
  • Non-flammable electrolyte
  • UL Approved --- BBCV2.MH30127
  • Quantity: 12 pcs

Electrical Characteristics

  • Nominal Capacity: 2.1Ah (2100 mAh)
  • Open Circuit Voltage: (at +20C +68F) 3.66V
  • Nominal Voltage: (at 1mA +20C +68F) 3.6V
  • Pulse Capability: Typically up to 120 mA
  • Diameter (max): 16.5 mm (0.65")
  • Height (max): 33.4 mm (1.31")
  • Typical Weight: 14.4 g (0.5 oz)

Key Features

  • High operating voltage, stable during most of the application lifetime
  • Some of the highest nominal capacities on the market today
  • Excellent reliability over extended operating life
  • Operating Temperature Range: -60°C/+85°C (-76°F/+185°F)
  • Low self-discharge rate (less than 1% after 1 year of storage at + 20°C)
  • Excellent resistance to humid environments
  • Low magnetic signature
  • Good resistance to passivation
  • Non-flammable (and non-pressurized at ambient temperature) inorganic (but corrosive) electrolyte
  • Less than 1% capacity loss during storage at ambient temperature before use
  • ½ AA, AA and A cell models non-restricted to transport
  • Up to 25 years of mass production experience
  • Excellent safety records
  • Compliant with IEC 86-4 safety standard and EN 50020 intrinsic safety standard
  • Compliance with the European directive RoHS

Equivalent Batteries

  • Saft LS17330-BA, LST17330, T32/41, T32/51, T32/8AA1 ER17/33

⚠️  Warning

  • This battery is not rechargeable. Do not try to recharge.
  • The storage area should be clean, cool (not exceeding +30 Deg C ), dry and ventilated
  • Please discharge the battery few minutes with 100mA,if the battery voltage is lower than your need or consult ABLE.
  • Don't use different models of battery in series.
  • Soldering the tab should be finished in few seconds.
  • Do not use if the battery casing was mangled

12-PACK SAFT LS17330 (ER17730) 3.6 VOLT 2/3 A 2100 MAH LITHIUM BATTERIES


Key Features:

High Capacity: Each battery provides a capacity of 2100mAh, ensuring long-lasting power for your devices.
Stable Operating Voltage: With a high operating voltage, these batteries offer stable performance throughout their lifespan.
Wide Operating Temperature Range: Designed to operate reliably in temperatures ranging from -60°C to +85°C (-76°F to +185°F), making them suitable for use in extreme environments.
Low Self-Discharge Rate: The batteries have a low self-discharge rate of less than 1% after 1 year of storage at +20°C, ensuring they retain their charge effectively during storage.
Excellent Reliability: Built to deliver excellent reliability over extended operating life, these batteries are trusted for critical applications where reliability is crucial.
Safe Design: Featuring a non-flammable electrolyte and hermetic glass-to-metal sealing, these batteries offer enhanced safety and durability.
Versatile Applications: Ideal for a wide range of applications including industrial equipment, medical devices, security systems, and more.


Specifications:

Voltage: 3.6 Volt
Chemistry: Lithium Thionyl Chloride (Li-SOCl2)
Brand: SAFT
Termination Style: Concentric (“bobbin”) electrodes
UL Approved: BBCV2.MH30127
Quantity: 12 pcs
Dimensions:
Diameter (max): 16.5 mm (0.65")
Height (max): 33.4 mm (1.31")
Weight: 14.4 g (0.5 oz)


Applications:

Industrial equipment
Medical devices
Security systems
Memory backup
Utility metering
GPS tracking devices
Data loggers
Wireless alarms
Portable communication equipment
And more


Compliance:

Compliant with IEC 86-4 safety standard and EN 50020 intrinsic safety standard
RoHS compliant

The SAFT LS17330 (ER17730) Lithium Batteries provide reliable power and excellent performance for a variety of applications. With their high capacity, wide operating temperature range, and long-term reliability, these batteries are the ideal choice for critical applications where dependable power is essential. Invest in SAFT LS17330 batteries and ensure the uninterrupted operation of your devices.
